Description
PROPERTIES
- Convection System
- Pre-heated combustion air
- Pre-heated secondary air supply
- Ash Can
- Airwash system
- Tertiary Air
TECHNICAL DATA
- 10 year limited warranty
- Gasketed seams for tight seals
- Chromium treated internal casting for durab
- Reversible flue collar
- Non catalytic burn technology
- Clean-burning air wash system
- Secondary air supply
FUEL
- Wood
APPROVALS
- EN/N
- DEFRA
- DIN+/AT
- EPA
- AS/NZS
SPECIFICATIONS
Maximum Heat | 30,000 |
Log size | 11″ |
Max. Area Heated | 1000 ft2 |
Firebox Dimensions | 13″ W x 10″ D |
Firebox volume/capacity | 0.744 ft3 |
Outside air supply | Available |
Gross Weight | 288 lbs |
Rated Output (kw) | 6 |
Operating Output (kw) | 3-6 |
Heats (m2) | 45 – 90 |
Height (mm) | 950 |
Width (mm) | 451 |
Dept (mm) | 386 |
Flue outlet top | Ø 125 |
Flue outlet rear | Ø 125 |
Weight (kg) | 110 |
Chamber Width (cm) | 30 |
CLEARANCE TO COMBUSTIBLES
Rear (mm) | 150 |
Sides (mm) | 400 |
Basic Clearance using single wall pipe top vent | |
Stove to side wall | 10″ |
Stove to rear wall | 3″ |
Stove to corner | 5″ |
Basic Clearance using double wall pipe top vent | |
Stove to side wall | 10″ |
Stove to rear wall | 2″ |
Stove to corner | 5″ |
