Description
Standard Features:
- Comes in Log, Birch Log or Glass media
- Viewing Area: 26 ¼” x 34 ¼”
- 30,000 BTU/hr Input – NG
- 30,000 BTU/hr Input – LP
- Electronic Ignition (IPI)
- Bayport 41 Log, Bayport 41 Birch Log, and Bayport 41 Glass only
- Rear-Vent Ready (top-vent convertible)
- Ceramic Glass
- Fan Kit CFM blowers
- Standard in Bayport 41 Log & Bayport 41 Birch Log
- Optional in Bayport 41 Glass
- Remote Control – Full Function
- High-Low Regulator
- Engineer-Designed burner system
- Minnesota Energy Code Compliant to 50 pascals
- Finish Trim Kit
- Certified to ANSI Z21.88 Vented Gas Heater
Efficiencies
- IPI
-
– ENERGUIDE P.4 NG/LP | 76.16% / 76.77%
-
– Steady State NG/LP | 77.96% / 78.04%
-
– AFUE % NG/LP | 72.19% / 72.16%
-
- LE
-
– ENERGUIDE P.4 NG/LP | 77.54 / 74.08
-
– Steady State NG/LP | 77.96% / 78.04%
-
– AFUE % NG/LP | 72.19% / 72.16%
-
- Efficiencies Glossary:
- – P.4 Efficiency (ENERGUIDE) is an efficiency rating more recognized in Canada to measure annual fireplace efficiency.
- – Steady State Efficiency is a measure of how efficiently your fireplace converts fuel to heat once it is warmed up and operating at a steady temperature.
- – Annual Fuel Utilization Efficiency (AFUE) is a measurement of the fireplace’s ability to convert fuel to heat over a longer period of time including the cycling on and off time period.
Standard Design Features:
- Enamel Refractory Lining
- Standard on the Bayport 41 Glass only
- Ember Bed Light Kit
- Standard on Bayport 41 Log & Bayport 41 Birch Log
- Accent Light Kit
- Standard on the Bayport 41 Glass
- Screen Front
- For options and pictures, look at the Bayport Brochure under the Resources tab.
Optional Features:
- Brick refractory lining
- Bayport 41 Log, Bayport 41 Birch Log
- Masonry refractory lining
- Bayport 41 Log, Bayport 41 Birch Log
- Black Glass refractory lining
- Optional on the Bayport 41 Log, Bayport 41 Birch Log
- Driftwood/Rock Accent Media
- Bayport 41 Glass only
- Beach Accent Kit
- Bayport 41 Glass Only
Required Design Features
- Glass Media
- Required with Bayport 41 Glass
- For options and pictures, look at the Bayport Brochure under the Resources tab.
English – Bayport Brochure
