Description
Technical specifications
| Nominal power (BTU/hr) | 11,695 – 28,231 |
| Heat input power (BTU/hr) | 11,695 – 28,231 |
| Dimensions H x L x P (inc) | 39,2 – 20,5 – 20,6 |
| Net weight (Lbs) | 272 |
| Pellet fuel consumption per hour min/max (Lbs/h) | 1.05 – 3.53 |
| Efficiency (min/max) | 80,73 |
| Flue exit pipe (Ø inc) | 3,15 (Rear) |
| Tank capacity (Lbs) | 33 |
| Burn time – min/max (h) | 8,88 – 21,44 |
| Installed power (W) | 59 |
| Energy class | A+ |
Technologies
-
Ash Tray
Comfortable and easy removable drawer to collect the ashes burnt.
-
Ceramic
Covering a stove with shapes and colours of majolica definitely increases its aesthetic value, while ensuring a better distribution of the heat.
-
Clear
An additional air channel, creates an air cushion between the flame and the glass -ceramic, guaranteeing its sharpness for several operating hours.
-
Firex
The special combustion chamber made of Firex 600/700, a vermiculitebased material, resulting from the research and development conducted by Ravelli.
-
Inox
The stainless steel heat exchanger increases the fire resistance while avoiding the classic problems linked to wear and tear.
-
RDS
The innovative system of self-regulation of combustion parameters to guarantee maximum efficiency and safety of your stoves.
-
Touch Remote
Remote control for switching on, and off, and adjusting the heater from distance and from different rooms than the one where the appliance is located.
